C Series Shading System

Obtain the look of our R Series Shading System at a fraction of the price. C Series, designed exclusively for commercial projects, features electroplated hardware with a brushed aluminum finish. As with R Series, wires and screws are concealed within the system, eliminating the need for valances, fascia, and ceiling pockets.

C Series Hardware


C Series brackets can be configured in a number of ways to accommodate unique architectural elements. The diameter of each shade roll is an identical match to each bracket profile, ensuring a seamless transition from shade to bracket. When shades are mounted in series, the matching profiles form a clean, continuous line.

Hardware Mounting Options:

  • Jamb Brackets (C1 and C2) can be mounted inside the window casing for a low-profile look. Each bracket is just under 2.5”in diameter.

  • Floating Brackets (C3 and C4) can be mounted outside of the window casing (to wall or ceiling).

  • Coupler Brackets (C5) can be mounted between shade rolls to create a shade wall.

Hardware Material Options:

  • Brushed aluminum - C Series brackets are injection molded polycarbonate with an electroplated finish.

C Series Power Options


Wired Motors

  • Wired motors can be integrated with building automation systems (Savant, Crestron, Lutron, Control 4, and more).

  • For buildings without a control system, wired motors can be linked to a keypad, remote, or app.

Battery Motors

  • Battery powered motors are rechargeable and can last more than a year on a single charge.

  • Battery life depends on shade size and frequency of use.

  • Batteries remain inside the shade tube while charging.

  • Battery motors can be controlled via remote or keypad.
